CAD Engineering &Plant Design Services
Precision engineering CAD services for EPC industries — from CAD conversion and plant layout to full 3D modelling and engineering automation. Delivered with zero-error quality assurance.
Engineering Services We Deliver
End-to-end CAD and plant engineering solutions tailored for EPC contractors, process industries, and infrastructure projects.
CAD Conversion & Drafting
Convert legacy drawings, PDFs, and paper blueprints into precise AutoCAD, MicroStation or Revit formats. Full 2D drafting and standards-compliant output.
- PDF to AutoCAD
- Paper-to-Digital
- Standards Compliance
- Revision Management
Vectorization Services
Raster-to-vector conversion of hand-drawn sketches, scanned PFDs, P&IDs, isometrics and engineering drawings with industry-grade accuracy.
- Raster-to-Vector
- P&ID Digitization
- Isometric Conversion
- Layer Management
Plant Design & Layout
End-to-end plant layout design for EPC projects — equipment arrangement, pipe routing, structural modelling and 3D clash detection using Smart 3D / PDMS.
- 3D Plant Modelling
- Equipment Layout
- Clash Detection
- PDMS / Smart 3D
Engineering Automation
Custom automation scripts, lisp routines and tool development to accelerate repetitive CAD tasks, reduce errors and dramatically cut delivery time.
- AutoLISP Routines
- Batch Processing
- Template Libraries
- Error Reduction
3D Modelling & Visualization
High-fidelity 3D models of piping systems, structural steel, pressure vessels and entire plant complexes for review, approval and client presentation.
- Piping Modelling
- Structural Steel
- Pressure Vessels
- Photo-Render Output
Quality Validation & QA/QC
Rigorous multi-stage QA/QC checks on all deliverables ensuring zero-error output — dimensional accuracy, symbol standards and compliance audits.
- Dimensional Checks
- Symbol Standards
- Compliance Audits
- Delivery Reports
Engineering Excellence at
Every Deliverable
RV TRANSCAT brings deep domain expertise and a dedicated CAD engineering team to deliver world-class results for EPC industries — precision, reliability and zero-error quality on every project.
Industries We Serve
Delivering precision CAD engineering across these sectors
How We Work
A systematic, quality-first approach that delivers precision on every project.
Discovery & Scope
We analyse your engineering drawings, source files and project scope to define deliverables and timelines.
CAD Processing
Our certified engineers convert, draft and model your project using industry-standard tools with precision.
QA/QC Review
Every deliverable undergoes multi-level quality checks before handover — zero-error is our standard.
Delivery & Support
On-time delivery in your preferred format with revision cycles and ongoing project support.
Ready to Elevate Your
Engineering Projects?
Talk to our engineering team today. Get a free project scoping session and discover how we can accelerate your CAD and plant design workflows.
